| Name | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
|---|---|---|---|---|---|---|---|---|---|
| Compact size | ①②③④⑤ | ①②③④ | ①②③④ | ①②③ | ①②③ | ①② | ①② | ①②③④⑤ | ①②③④⑤ |
| High production | ①② | ①②③ | ①②③④ | ①②③④ | ①②③④⑤ | ①②③④ | ①②③④⑤ | ①② | ①②③ ④ |
| Flexibility | ①②③ | ①②③ | ①②③④⑤ | ①②③④⑤ | ①②③④⑤ | ①②③④⑤ | ①②③④⑤ | ①②③④ | ①②③ |
| Quick ROI | ①②③④⑤ | ①②③④⑤ | ①②③④ | ①②③④ | ①②③④⑤ | ①②③④ | ①②③④ | ①②③④⑤ | ①②③④⑤ |
| Key features decide selection | |||||||||
| General | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
| Machine picture |
|
|
|
|
|
|
|
|
|
| Machine motion schematic | |||||||||
| PC control(Windows 10) | S | S | S | S | S | S | S | S | S |
| Power supply | 1PH 220V | 3PH 380V | 3PH 380V | 3PH 380V | 3PH 380V | 3PH 380V | 3PH 380V | 1PH 220V | 3PH 380V |
| Machine dimension(W*D*H) | 950*1368*1746 | 1260*1643*1942 | 1830*1730*1660 | 2950*1731*1720 | 3635*1966*1720 | 5650*1865*1720 | 5650*1865*1720 | 1386*1917*1418 | 1386*1917*1418 |
| SMEMA | N | N | S | S | S | S | S | S | S |
| Scanner for data collection | O | O | O | O | O | O | O | O | O |
| Follow me function | N | N | O | O | O | O | O | O | O |
| Conveyor | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
| Conveyor | Offline | Offline | Inline | Inline | Inline | Inline | Inline | Inline | Inline |
| Conveyor lane quantity | no | no | single lane | single lane | single lane | single lane | single lane | single lane | single lane |
| Auto conveyor width adjustment | no | no | S | S | S | S | S | S | S |
| Conveyor section | no | no | 2 | 3 | 3 | 5 | 5 | 1 | 1 |
| Max soldered area | W350xL260mm | W350xL450mm | W508xL891mm | W508xL508mm | W600xL600mm | W508xL508mm | W508xL508mm | W350xL450mm | W508xL508mm |
| Fluxing function | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
| Fluxing function | S | S | S | S | S | S | S | S | S |
| Flux nozzle type | drop jet | drop jet | drop jet | drop jet | drop jet | drop jet | drop jet | drop jet | drop jet |
| Flux nozzle number | 1 | 2 (standard) | 2 (standard) | 1 (optional 2) | 2 (standard) | 1 (optional 2) | 2 (standard) | 1 | 2 (standard) |
| Flux tank number | 1 | 2 (standard) | 2 (standard) | 1 (optional 2) | 2 (standard) | 1 (2 when optional 2nd flux nozzle) |
2 (standard) | 1 | 2 (standard) |
| Cleaning solvent tank number | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| One button cleaning flux nozzle function | S | S | S | S | S | S | S | S | S |
| Flux level alarm | S | S | S | S | S | S | S | S | S |
| Cleaning solvent level alarm | S | S | S | S | S | S | S | S | S |
| Auto fluxer distance adjustable | N | Manual | S | O | S | O | S | N | Manual |
| Two type of flux | N | O | Capable | Capable | Capable | O | O | O | O |
| Preheating function | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
| Preheating function | S | S | S | S | S | S | S | S | S |
| Bottom preheating function | S | S | S | S | S | S | S | S | S |
| Bottom preheating type | IR | IR | IR | IR | IR | IR | IR | IR | IR |
| Bottom preheating Zones | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 1 | 1 |
| Top preheating function | O | O | S | S | S | S | S | N | N |
| Top preheating type | IR (Optional) | IR (Optional) | IR | Hot air | Hot air | Hot air | Hot air | N | N |
| Upper heating in soldering module | O | O | S | S | S | S | S | N | N |
| Failure monitoring IR heater | O | O | O | O | O | O | O | O | O |
| Soldering function | Ant-i1 | Ant-i2 | NuFlex-i2 | MAS-i2 | MAS-i4 | MAS-i22/1 | MAS-i24/1 | Unit-i1 | Unit-i4 |
| Soldering function | S | S | S | S | S | S | S | S | S |
| Solder pot number | 1 | 1 | 2 | 2 | 2 | 2 | 4 | 1 | 2 |
| Solder pot distance adjustment | N | N | Auto | Auto | Auto | Auto | Auto | N | Auto |
| Solder tunnel number (solder nozzle) | 1 | 2 | 2 | 2 | 4 | 2 | 4 | 1 | 4 |
| Two type of solder | No capable | No capable | Capable | Capable | Capable | Capable | Capable | No capable | Capable |
| Automatic solder wire feeder | O | O | O | O | O | O | O | O | O |
| Automatic nozzle cleaning | O | O | O | O | O | O | O | O | O |
| Automaic wave height calibration | S | S | S | S | S | S | S | S | S |
| Live-on camera for soldering | S | S | S | S | S | S | S | S | S |
| Fiducial recognition | O | O | O | O | O | O | O | O | O |
| N2 heating | S | S | S | S | S | S | S | S | S |
| N2 flow monitoring | O | O | O | O | O | O | O | O | O |
| N2 purity montioring | O | O | O | O | O | O | O | O | O |
| Mechanical solder pump (15kgs capacity) |
S | S | S | S | S | S | S | S | S |
| Mechanical solder pump for wide wavenozzle (30kgs capacity) |
N | N | N | O | N | O | O | N | N |
| Replace mechanical pump with Electro-magnetic pump (15kgs capacity) |
O | N | O | O | N | O | O | O | N |
| S: Standard | O: Optional | N: Not avaliable | |||||||
